Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 338
e set rings at theback of the die. A circular spring throws out the cutters. Cross sec-tion. 1343. Front view. 1344. Longitudinal section. 1345. Outside view. 1346. UNIVERSAL CHUCK, for eccentric turning. The dividedgear plate and chuck-ing screw are re-volved and held atany division by thespring…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
