Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 317

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 317
available; but the subject is a valuablestudy. 3l6 TEXTILE AND MANUFACTURING DEVICES, ETC. 8i8. THREE-STRAND CORDAGE MACHINE. The armedcarrier wheels, K, H, T, are fast on the driving shaft, S, which is driven by a gear wheelmeshed with thethree pinions re-v-olving thespools, G, for a©^ back twist… … 820. THIRTY-TWO STRAND CORDAGE MACHINE. A fine study of the mechanical motions required in this complicated

Mechanical movements
