Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 379
10. ELLIPSO-GRAPHIC T U R X -TABLE. — The tablesits upon a trammelframe, which moves abar with gimbal yokeand sliding rod to carrythe pen or pencil., Makes,an ellipse froma circle to • a straightline. 1531&. ELLIPSOGRAPH.—A pairof dividers with points perforated likethe eye of a needle allows… … 1531a. OMNI-TELEMETER.—For obtaining the distance of an ob-ject by two observations on a line atright angles. A, direct line ofsight through the half silvered mir-ror D; X, reflected line of sight at90° or variable by the mirrors D, F.The lever L varies the angle of themirror, F, by means of the…
Mechanical movements
