e-ing seated in a pocket fixed on the spoke ofthe wheel, or in some cases attached directlyto the rim of the wheel. The inner eccentric,marked (\ having ears attached, is placed close to the regulator-wheel, and is free to turnupon the .shaft. From the ears rods (2 2) are connected with the reguhir… … Fig. 7.—Gidflings governor.
