Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 404

An illustration from Mechanical movements, powers and devices, 1911, leaf 404 — 1635. ACETYLENE BURNER, made oflava. The burner holes are at an angle of90° on inner face of the arms. The air-mix-ing holes are on each side of the arms. Ger-man. Gleason Manufacturing Company, … 1636. ACETYLENE BURNER.—A doubleflame burner at right angles. The small holesin the sides of the tips allow air to enter andmingle with the acetylene gas before it is.ignited, thus making a mixture of gas and airthat makes a clear flame and a safe burner. TLsn B 1637. BAYONET JOINT.—The pin fixed…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
