Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 404
1634. ACETYLENE GENER-ATOR AND GAS HOLDER.—The carbide is charged into thesmall vessel suspended from thecross pipe, with a stopcock above.A connection for a second carbidevessel is also seen. Water fromthe holder runs through a jointedpipe and drips into the sealed fun-nel. The water nozzle is… … 1635. ACETYLENE BURNER, made oflava. The burner holes are at an angle of90° on inner face of the arms. The air-mix-ing holes are on each side of the arms. Ger-man. Gleason Manufacturing Company. 1636. ACETYLENE BURNER.—A double flame burner at right angles. The small holesin the sides of the tips…
