An illustration from Mechanical movements, powers and devices, 1911, leaf 406 — HOTCHKISS MAGAZINE GUN.—The reserve cartridgesare carried in the gun stockand forwarded by a light spring.The breech bolt draws back bythe handle, when the cartridgeis raised and pushed forward into the barrel. Centre pin spring hammer.
