Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 80
227. COMPOUND OSCILLATINGENGINE.—Cylinders at right angles. … 228. TWIN-SCREW OSCILLAT-ING ENGINE.—A through piston rodconnects directly to crank-pins on theshaft face plates. Suitable for smallboats. 229. OSCILLATING HOIST-ING ENGINE.—The piston rodsare attached to an eccentric strap;one fixed, the other pivoted. A leveroperated by the same eccentric…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
