257. JOYS VALVE GEAR for a ver-tical engine. Operated from a pin in theconnecting rod. Reversal is made by changing the position of the slotted link … JOYS VALVE GEAR for a horizontal engine. Adjust-ment is made by the angular position of the slottedlink. Valve motion by crankrod and links. 76 STEAM POWER.
