371. PARSONS STEAMTURBINE. —A series of discsfixed on a shaft with intersectingdiscs on the shell. The face of theshaft discs has several small bladesset at an angle with the radius.The outside fixed disks have a sim-ilar set of blades interlocking withthe revolving blades and set at a contrary… … ^77777777777< 371a. CRUDE PETROLEUMBURNER with concentric fixed noz-zles. One of many varieties in use.I, oil feed; 2, steam feed; 3, air inlet.Further air regulation is made outsidethe nozzles. 371&. THE HAMMEL CRUDEOIL BURNER. Gives a broad flame. A, oil supply; B, steam supply; C,mixing…
