Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 107

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 107
pair and outward again. … 371a. CRUDE PETROLEUMBURNER with concentric fixed noz-zles. One of many varieties in use.I, oil feed; 2, steam feed; 3, air inlet.Further air regulation is made outsidethe nozzles. 371&. THE HAMMEL CRUDEOIL BURNER. Gives a broad flame. A, oil supply; B, steam supply; C,mixing chamber. E, steam…

Mechanical movements
