econd winding of the field magnets is in series ordirect connection with the outer circuit. The shuntwinding should be small wire. S, Shunt connected with armature brush holders; S, large wire field winding in main circuit. 716. CONSEQUENT-POLECOMPOUND GENERATOR.—The opposite field pieces arewound… … 192 ELECTRIC POWER AND CONSTRUCTION.
