Mechanical movements, powers and devices (1907)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 209

An illustration from Mechanical movements, powers and devices, 1907, leaf 209 — 744. ELECTRIC SAD IRON.—The ironis a shell frame with a smooth face on thebottom. A resistance coil made of iron,German silver, or platinum, insulated with as-bestos, is wound in spirals as near the bot-tom plate as can be made available for thegreatest amount of heat. … 745. ELECTRIC SEARCHLIGHT,Edison model. An arc light in front ofand in the focus of a concave reflector.It gives a beam of light nearly parallel.The front of the case has a plane glassfor protection. It swivels in all direc-tions. ELECTRIC POWER AND CONSTRUCTION. 199
