o the terminal connecting rod. 924. ALTERNATING RECIPROCAL MO-TION from two crank gears and connecting rodsto a walking-beam. When the gears are equalthe motion of the rod is uniform; when the gearsare unequal the motion of the rod is proportionallya varying differential one. 925. TWO-TOOTHED… … 926. PIN WHEEL AND SLOTTED PINION, by which a change of speed is obtained by shifting,the pinion along its shaft. 927, VARIABLE ROTARY MOTION fromcone gears. A tootlied cone is matched to aninverted cone with pin teeth to gear with the vari-able pitch of the cone teeth. 928. SCROLL GEAR.—Increasing…
