Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 246
924. ALTERNATING RECIPROCAL MO-TION from two crank gears and connecting rodsto a walking-beam. When the gears are equalthe motion of the rod is uniform; when the gearsare unequal the motion of the rod is proportionallya varying differential one. 925. TWO-TOOTHED PINION.—Transmis-sion of motion to a… … 926. PIN WHEEL AND SLOTTED PINION, by which a change of speed is obtained by shiftingthe pinion along its shaft. 927. VARIABLE ROTARY MOTION from cone gears. A toothed cone is matched to aninverted cone with pin teeth to gear with the vari-\ able pitch of the cone teeth. 928. SCROLL…
Mechanical movements
