^ the revolution of an eccen-tric bearing at the bottom ofthe shaft, driven by bevelgearing. The crushing conehas a slow rotation due to dif-ferential areas of cone and sta-tionary plates at the bottom ornearest contact surfaces. MIXING. 3ii … 1259c. HAND POWER ROCKDRILL, Jackson model.—A power-ful helical spring drives the drillforward. The crank operates a camwiper for drawing back the drill;the motion is regulated by the flywheel.
