PUNCHINGMACHINE.—The tire is made fast by the cam jaws, and the mov-able cam is set forwardby the sector cam leverand pinion. A punch isattached to the movablejaw with a punch die inthe horn of the machine,so that the same opera-tion of upsetting a tiremay be used for punch-ing iron. 1370. Vertical…
