An illustration from Mechanical movements, powers and devices, 1907, leaf 349 — 1401. SCREW THREADS, Trape-zoidal thread. Angle 90° face, 45 « back.Depth equals 0.75 of the pitch. 338 MILL AND FACTORY APPLIANCES. … POWELLS i<—pHTHREAD
