Mechanical movements, powers and devices (1907)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 349
POWELLS i<—pHTHREAD … 1402. SCREW THREADS, squarethread. Angle square. Depth equals -|-half pitch. Width between threads equal4- half pitch, for clearance. 1403. SCREW THREADS,Powellsthread. Depth of thread equals -f- halfpitch. Width of top of thread, 0.37-ofpitch. Width of bottom, 0.37 -f of pitch.Angle of side, 11^…Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
