Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 367
5 -S^ F % 1479. TIMBER SPLICING.? —Butt joint with timber fish plate,keyed and bolted. ,m> im. 1^ .Qi /a, o 1480. TIMBER SPLICING. ] —Butt joint with double ^ timber fish plates, bolted. <&. -w- gT -^ ■^ :^i i*^! -U——CJ GT =^ 1481. TIMBER SPLICING.— Compression beams butted and heldby a… … 1483. TRUSS ROOF. a, tie beam. <^, principal rafter. r, common rafter. d, king post. e, strut. 1484. QUEEN POST ROOF TRUSS. a, tie beam; r, c, queen posts; d, d, braces; e, truss beam; /, straining piece; g, g, prin-cipal rafters; h, cambered beam; b, iron string bolt to support tiebeam.
Mechanical movements
