1647 MAUSER RIFLE.—Magazine in theforestock. The slid-ing breech blockencloses the firingspring plunger andraises the cartridgelever A. 396 MISCELLANEOUS DEVICES. 1648. WINCHESTER MAGAZINE RIFLE.— The breech lock slidesin line with the barrelby a toggle link, oper-ated by the breech le-ver, which…
