Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 44
75-76. BELT LACING, fornarrow belt. Commencing at a, aon the inside of belt 75, drawingthe lacing to its centre; rove theends each way, ending at e, e, 76. OA … 77. BELT LACING.—Com-mencing at A and ending at B.Dotted lines on outside. 78. OVER-AND-OVER LACING.^—Commencing at A andending at B. Diagonal on outside. 79. INTERLOCKING BELTLACING, from A to B, onceacross. A good style for smallpulleys. 80. CROSS LACING, for alight belt. 81. OVER-AND-OVER…
Mechanical movements
