150. BOURDON PRESSURE GAUGE—A flattened spring metal tube is bent toa circular form. One end is fixed to theinlet stud; the other end is connected toa lever sector by a link. The sector ismeshed with a small pinion on the arborcarrying the index hand. A hair springattached to the arbor keeps all… … 151. CORRUGATED TUBE-PRESSURE GAUGE.—The pressure within the tube expands it on the cor-rugated side and through the link connections withthe index hand moves the hand. MEASUREMENT OF POWER. 51
