Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 90
274. PARALLEL MOTION, usedside-lever marine engines.E, cross-head. C, F, radius bar. D, E, parallel bar. on … 275. PARALLEL MOTION, for alever marine engine. a and b are of equal length.c and d are of equal length. Radius of rocker-shaft crank F = — e side
Mechanical movements
