Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 127

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 127
421C. STEAM SOOT SUCKER forcleaning boiler tubes by drawing the sootand ashes from the tubes by an annularsteam jet. Ii6 STEAM APPLIANCES. … 421 d. AIR COOLING TOWER.—Forcooling the water of a surface condenser.The hot water is forced to the top of thetower and distributed over a large surfaceof tile through which air is circulated bythe large fan at the bottom of the tower.The water much cooled drips to the tankbelow from which it is…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
