Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 123

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 123
421c, STEAM SOOT SUCKER forcleaning boiler tubes by drawing the sootand ashes from the tubes by an annularsteam jet. ii6 STEAM APPIylANCES. … 42id. AIR COOLING TOWER.—Forcooling the water of a surface condenser.The hot water is forced to the top of thetower and distributed over a large surfaceof tile through which air is circulated bythe large fan at the bottom of the tower.The water much cooled drips to the tankbelow from which it is…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
