An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 142
achine is mounted on a pair ofhigh wheels having serrations orteeth projecting from the treadsurface, and the inner portion ofthe rim carries a continuous gearadapted to rotate the drag, throughthe small gear wheel and chain ar-rangement on either side of themachine. Section VII. HYDRAULIC POWER… … OVERSHOT WATEP. WHEEL, withsteel buckets. Witli the gate chute im-pinging upon the buckets an efficiency offrom seventy to seventy-five per cent, maybe obtained. h X w X .70 = horse-power. 33,000 h, Total height of water-fall from race; w,weight of water falling per minute.

Mechanical movements
