547. EJECTOR OR JET PUMP, with forked sue-tion pipes. 548. EJECTOR OR JET PUMP. A, the steam nozzle. B, suction pipe. C, the force pipe.A crude representation of the earlier forms of the ejector. 11 549. AUTOMATIC WATER EJECTOR.—Cel A^ lars and swamps may be drained, where there is awater supply… … HYDRAULIC POWER AND DEVICES. 149
