Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 174

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 174
6iib. MILK COOLING DE-VICE.—Milk is fed from a tank overthe surface of a hollow copper pan,corrugated to retard its flow, whilecold water is circulated through thepan in the opposite direction. … 6iif.HYDRAULICIRRIGATION ENGINE.—Capacities up to 750,000gallons per day. They aremade adjustable for thebest conditions of opera-tion by the sliding weighton the valve lever. Thedouble acting type willpump pure spring water bythe use of impure water ofstreams. Will run on 2 feetfall. Rife Engine…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
