Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 180
FAN BLOWER.—An ordinary model as used for blowing forge fires HODGES COMPOUND BLOWER.— The action is a triple effect. The air isdrawn in at each side of the blower andthrown out at increasing pressure succes-sively by the fans on each side, and returnedsuccessively by the stationary partitions,with… … 628. « WEDDING ROTARY BLOWER—A swinging winged cylinder moving in contactwith an outer shell. The wing rides in a slotin the shell with a cavity to give it freedom ofmotion. The central cylinder is driven by acrank-pin or eccentric on a shaft central with theshell
Mechanical movements
