Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 196

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 196
689. TORCH SOLDERINGCOPPER.—The conical tip ismade of copper, and slips onto the nozzle of a plumbersgasoline torch. Used largelyfor electric wire connections. AIR POWER APPLIANCES. 8S … 690. AIR AND GASOLINE VAPOR BRA-ZER, double flame. The pressure of vapor tothe Bunsen burners is regulated by a valve nearthe top of the tank. The valve handles hangingfrom the stems regulate each burner. 691. AIR AND GASOLINE BRAZINGAPPARATUS.—A small attached pumpforces air into a tank holding a…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
