Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 209

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 209
742. ELECTRIC HEATER.—Coils of German silver wirewound around asbestos cords and rove over porcelain buttons forinsulation. The buttons may be fastened to a frame of any requiredform. <1ZI[>=^X 743. ELECTRIC SOL-DERING COPPER.— The copper is wound witha coil of resisting material; platinum… … 744. ELECTRIC SAD IRON.—The ironis a shell frame with a smooth face on thebottom. A resistance coil made of iron,German silver, or platinum, insulated with as-bestos, is wound in spirals as near the bot-tom plate as can be made available for thegreatest amount of heat.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
