Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 219

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 219
PSAIL SLOOP.—A mainsail, two jibs and jib-topsail. The topsail is runup the topmast and extended on the gaff.Main jib-stay from masthead to bow. Forejib-stay from topmast to bowsprit. i, flying-jib; 2, jib ; 5, mainsail; 13, gaff-topsail. 775. THE CUTTER.—A mainsail, 5 ; jib,2 ; flying-jib, i, and… … 777. FULL SCHOONER RIG—Main- and fore-sail, two or three jibs,and two topsails, i, flying-jib ; 2, jib:3, foretop staysail; 4, foresail; 5, maift-sail; 12, fore gaff-topsail; 13, maingaff-topsail.
