Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 214

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 214
772. SKIFF YAWL RIG.—A mainsail withone or two jibs, and a small mast at the stemwith a leg-of-mutton sail, extended by a boom.I, flying-jib; 2, jib; 5, mainsail; 8, lugsail. SLOOP YAWL.—A foremast, schooner-rig, ofsheet and jib, with a lugsail and mast at thestern. Lugsail extended by a boom. 2,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
