819. VERTICAL BUCKET PADDLE WHEEL.—The buckets, «, a, a, a, are pivoted to the shaft arms,b, I?. To the pivots are attached cranks, r, c, c, cwhich are pivoted to the arms of an eccentric ring re-volving with the shaft on a fixed eccentric, e. By thisarrangement the buckets are kept vertical. … 820. FEATHERING PAD-DLE WHEEL.—The buck-ets are hinged with back le-vers and turned to their properposition by arms pivoted ec-centric to the shaft. Theframework of the wheel is ofiron or steel. 821. Cross section. NAVIGATION AND ROADS. 215
