844. ROAD BUILD-ERS LEVEL. —A drawtelescope, on a screw andswivel base, with arm andscrew for small adjustment.The bubble is directlyunder and in focus of theeyeglass, and is seen byreflection from a piece ofglass at 45 ° in the eyepiece. 845. Section through reflector and level. NAVIGATION AND… … 846. ROAD MACHINE,for scraping and levellingcommon roads. 847. REVERSIBLE ROADROLLER.—The tongue is at-tached to the frame that carriesthe drivers seat, and is bal-anced by the weight on therear arm. By unlocking thecatch the horses wheel aroundthe roller with the tongue andseat frame, and the…
