857. GASOLINE MOTORCARRIAGE.—Two full seatsand single seat for driver. Themiddle seat turns over to getat the motor and gear. 858. LIGHT ELECTRICCARRIAGE, with singleseat. The motor is attachedto the frame and gearedto a speed shaft, and bysprocket and chain to thewheel axle. 222 NAVIGATION AND… … ELECTRIC PHAETON.— The motors are fixed to aframe under the floor of thephaeton, with their pinionsmeshing with an inside spurgear on each wheel. Thebatteries are under the seatand extension box over thedriving wheels.
