Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 249
932. BALL GEAR with traverse pinions,a very limited traverse of the pinions. Has 933. SPIRAL GEARING.—V gearing, in which the teeth are at a small angle with the plane of rota-tion, makes a perfectly silent transmission of power. … 934. EXPANDING PULLEY—The sec-tional rim pieces with their arms have a radialsliding joint on the hub arms, and are movedout or in by pins projecting into the spiralslots on the central spur-gear wheel. Themovement of the wheel c, by turning the ratchetpinion d^ moves all the sections of the…
Mechanical movements
