942. REVOLUTION OF A PINION aroundits own centre and also around the common centreof two externally centred gears, a^ driving pulleywith cross band to gear pulley b^ and direct bandto gear pulley c. The differential motion revolves thepinion D around its own axis and around its externalaxis b. A…
