Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 264

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 264
e ratchet bar A andlifts the bar. The slot serves as guide. The othermember may be a suspension or standard attach-ment. Much used in ratchet jacks and stump-pullers. A^ 995. RATCHET GOVERNOR, forwater-wheels or other prime movers.B |i=^^) y—^. The pin cam is in constant revolution.^ P The… … 996. ROTARY MOTION, from reciprocatingmotion of two racks alternately meshing with agear wheel. Racks are pinioned at <7, a. Thecurved slots b, b guide the racks out and intogear. The bell-crank lever c and spring d serveto disengage the rack at the end of the up-stroke. 254 MOTION AND DEVICES…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
