1068. TOGGLE-JOINT CAM MOVE-MENT for throwing out a number of grips aionce by the local movement of the jointedring. 1069. DOUBLE-SCREW TOGGLE PRESS—The screw has a right- and left-hand thread to drawthe toggle joints together. r—^ … 1070. SCREW STAMPING PRESS.—Reo tilinear motion from the circular motion of them lever handles. The momentum of the balls givesthe final power in this class of presses. 1071. MULTIPLE RETURN GROOVEDCYLINDER, producing extended rectilinearmotion and return by its revolution. The car-rier arm has a…
