The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 174
Fig. 169.—Lifter Motion (J. Hetherington & Sons) A, Shaper plate, b. Stud bracket, c, Rack pinion. D, Bevel on upright shaft. E, Tapering bevel gearingwith bevel on upright shaft. F, Ratchet change pinion circles small; the motions of the lifter plate or rail are thereforeshort. Gradually,…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
