Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 321

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 321
1259a. DISINTEGRA- TOR, for pulverizing ore.Two concentric shafts withdisks and beating bars run-ning at high velocity in oppo-site directions. … 12596. ORE CRUSHER,GATES MODEL.—The coneon the central shaft is made tovibrate in a circular directionby the revolution of an eccen-tric bearing at the bottom ofthe shaft, driven by bevelgearing. The crushing conehas a slow rotation due to dif-ferential areas of cone and sta-tionary plates at the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
