Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 120

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 120
273. GASOLINE ATOMIZER AND VAPORIZER The exhaust … Hay type,is used forheating the walls of the va-porizing chamber by trav-ersing the annular cham-ber e. A fan, h^ is revolvedon the spindle, y, by the in-rushing air and gasolinethrough the valve E, whichalso covers the gasoline in-lets on the face of the valveseat and is connected withthe annular…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
