Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 331

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 331
1303. SIMPLE FRICTION PULLEY.—Theself-acting clutch arms act upon the pulley rim inone direction only. When shaft motion is reversed,the pulley is free. 1304. FRICTION CLUTCH.—A conical-grooved pulley and clutch rim. The clutchslides on the shaft and feather, and is controlledby a lever and carrier… … 1306. CLUTCH AND GEAR.—The clutch slides on the feathered shaft, andthrows the gear into motion by the operationof the bell-crank lever and runner. MILL AND FACTORY APPLIANCES. 321 fl 1307. CONE CLUTCH.—Can be made at11—}^ any angle greater than will cause the clutch to stick. 1308. MULTIPLE PLATE…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
