Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 346
ETURN MOVEMENT for a cutter head. A constant rotation of the camoperates the bell-crank sector, which is quicklydrawn back by the weight W and pinion C. 1383. REVERSING GEAR, from asingle belt and cone pulley. The gearwheel a has an outside and inside set ofteeth with the pinions ^, c meshing… … 1384. FLEXIBLE UNIVERSAL STEAMJOINT.— Hampson model. The steam flowsthrough the thick arms of the Y*s, which haveground joints. 1385. BYE PASS COCK OR VALVE.--To allow of a small delivery when thelarge valve is closed, or for relief of press-ure against a large valve.
Mechanical movements
