Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 358

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 358
1443^. CONICAL ROLLERTHRUST BEARING.—The conicalrollers are held in ring travellers, in-side and outside, which are connectedtogether between the rollers. The conical lines meet at the centerof the shaft. … 1443^. STEAM VULCANIZERfor repairing bicycle tires.—Two steamslabs and tightening screw set on asmall boiler heated by a lamp or torch;steam pressure should be 75 lbs. persquare inch. Small clamps and screwsare attached to the top steam box forvulcanizing other articles. The lowersection is the…

Mechanical movements
