Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 359

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 359
1443/. STEA^I VUL-CANIZER for repairingbicycle tires and bands.—The cast iron bed piece ishollow to hold sufficientwater for making steam,which should be at 75pounds pressure. Com-pression is made by thelever and weight for bothtires and bands. A gas orgasoline torch for heating. … the slidinsr bar is fixed. 14430. RIGHT ANGLE SHAFTTRANSMISSION.—A bell cranksliding on a cross bar is pivoted at itsends to the crank pins of shafts atright angles. The crank pins havesliding sleeves pivoted to the bellcrank arms. The movement is en-closed in an oil-tight case to whichHorizontal…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
