Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 412

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 412
WITH TWOLEVERS AND ONE LINK.—Levers A and F are connectedby link D to frame /. Lever A, with a handle, is pivoted toframe J at B and connected to link D at C. Link D, connected to lever A at C, is connectedto lever F at E. Lever F,connected to link D at E, ispivoted to frame J a.t G andronnected to… … 1663. OIL SWITCHLEVERS AND ONE LINK. MOVEMENT WITH TWO-Levers A and E are connectedby link L to frame /. Lever Ais pivoted to frame J a.t B andconnected to link L at C. LinkL, connected to lever A at C, isconnected to lever £ at D.Lever E, connected to link L atD, is pivoted to frame / at Fand…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
