washers. 114. GROOVED FRICTION GEARING.—The 11^ loss of power by friction increases with the size anddepth of the grooves. Friction increases inversely as theangles of the grooves. 115. VARIABLE MOTION to a shaft in lineby curved-faced discs, with a swinging pulleypivoted central to the curves on… … 40 TRANSMISSION OF PO^VER. ii6. TRANSMISSION OF CIRCULAR MOTIONby right-angled cranks on each shaft. The pair of crankconnections carry the right-angled cranks over the centre.The principle of the locomotive wheel connections. 117. THREE CRANK LINK connection for transmission of motion to a crankby…
